Plot Personal Best (PB) Trends

Visualizes the trend of personal best times for specific running distances.

Usage

plot_pbs(
  data,
  activity_type = "Run",
  distance_meters,
  max_activities = 500,
  date_range = NULL,
  add_trend_line = TRUE,
  pbs_df = NULL
)

Arguments

data

Recommended: Pass pre-calculated data via pbs_df (local export preferred). A data frame from calculate_pbs() or activities data from load_local_activities().

activity_type

Type(s) of activities to search (e.g., "Run"). Default "Run".

distance_meters

Numeric vector of distances (meters) to plot PBs for (e.g., c(1000, 5000)). Relies on Strava's best_efforts data.

max_activities

Max number of recent activities to check. Default 500. Reduce for speed.

date_range

Optional. Filter activities by date c("YYYY-MM-DD", "YYYY-MM-DD").

add_trend_line

Logical. Whether to add a trend line to the plot. Default TRUE.

pbs_df

Recommended. A pre-calculated data frame from calculate_pbs(). When provided, analysis uses local data only (no API calls).

Value

A ggplot object showing PB trends, faceted by distance if multiple are plotted.

Details

Plots the trend of best efforts for specified distances, highlighting new PBs. Recommended workflow: Use local data via pbs_df.

Visualizes data from calculate_pbs. Points show best efforts; solid points mark new PBs. Y-axis is MM:SS. Best practice: Use load_local_activities() + calculate_pbs() + this function. Legacy API mode is maintained for backward compatibility only.

Examples

# Example using the built-in sample data
# This data now contains a simulated history of performance improvements
data("athlytics_sample_pbs", package = "Athlytics")

if (!is.null(athlytics_sample_pbs) && nrow(athlytics_sample_pbs) > 0) {
  # Plot PBs using the package sample data directly
  p <- plot_pbs(pbs_df = athlytics_sample_pbs, activity_type = "Run")
  print(p)
}
#> Generating plot...
#> `geom_smooth()` using formula = 'y ~ x'


if (FALSE) {
# Example using local Strava export data
activities <- load_local_activities("strava_export_data/activities.csv")

# Plot PBS trend for Runs (last 6 months)
pb_data_run <- calculate_pbs(activities_data = activities,
                             activity_type = "Run",
                             distance_meters = c(1000,5000,10000),
                             date_range = c(format(Sys.Date() - months(6)),
                                          format(Sys.Date())))
if(nrow(pb_data_run) > 0) {
  plot_pbs(pbs_df = pb_data_run, distance_meters = c(1000,5000,10000))
}

# Plot PBS trend for Rides (if applicable, though PBs are mainly for Runs)
pb_data_ride <- calculate_pbs(activities_data = activities,
                               activity_type = "Ride",
                               distance_meters = c(10000, 20000))
if(nrow(pb_data_ride) > 0) {
   plot_pbs(pbs_df = pb_data_ride, distance_meters = c(10000, 20000))
}

# Plot PBS trend for multiple Run types (no trend line)
pb_data_multi <- calculate_pbs(activities_data = activities,
                               activity_type = c("Run", "VirtualRun"),
                               distance_meters = c(1000,5000))
if(nrow(pb_data_multi) > 0) {
  plot_pbs(pbs_df = pb_data_multi, distance_meters = c(1000,5000),
           add_trend_line = FALSE)
}
}
