Plot Aerobic Decoupling Trend — plot

Visualizes the trend of aerobic decoupling over time.

Usage

plot_decoupling(
  data,
  activity_type = c("Run", "Ride"),
  decouple_metric = c("pace_hr", "power_hr"),
  start_date = NULL,
  end_date = NULL,
  min_duration_mins = 45,
  add_trend_line = TRUE,
  smoothing_method = "loess",
  decoupling_df = NULL
)

Arguments

data: Recommended: Pass pre-calculated data via decoupling_df (local export preferred). A data frame from calculate_decoupling() or activities data from load_local_activities().
activity_type: Type(s) of activities to analyze (e.g., "Run", "Ride").
decouple_metric: Metric basis: "pace_hr" or "power_hr".
start_date: Optional. Analysis start date (YYYY-MM-DD string or Date). Defaults to ~1 year ago.
end_date: Optional. Analysis end date (YYYY-MM-DD string or Date). Defaults to today.
min_duration_mins: Minimum activity duration (minutes) to include. Default 45.
add_trend_line: Add a smoothed trend line (geom_smooth)? Default TRUE.
smoothing_method: Smoothing method for trend line (e.g., "loess", "lm"). Default "loess".
decoupling_df: Recommended. A pre-calculated data frame from calculate_decoupling(). When provided, analysis uses local data only (no API calls). Must contain 'date' and 'decoupling' columns.

Value

A ggplot object showing the decoupling trend.

Details

Plots the aerobic decoupling trend over time. Recommended workflow: Use local data via decoupling_df.

Plots decoupling percentage ((EF_1st_half - EF_2nd_half) / EF_1st_half * 100). Positive values mean HR drifted relative to output. A 5\% threshold line is often used as reference. Best practice: Use load_local_activities() + calculate_decoupling() + this function.

Examples

# Example using pre-calculated sample data
data("athlytics_sample_decoupling", package = "Athlytics")
p <- plot_decoupling(decoupling_df = athlytics_sample_decoupling)
#> Generating plot...
print(p)
#> `geom_smooth()` using formula = 'y ~ x'


if (FALSE) { # \dontrun{
# Example using local Strava export data
activities <- load_local_activities("strava_export_data/activities.csv")

# Example 1: Plot Decoupling trend for Runs (last 6 months)
decoupling_runs_6mo <- calculate_decoupling(
    activities_data = activities,
    export_dir = "strava_export_data",
    activity_type = "Run",
    decouple_metric = "pace_hr",
    start_date = Sys.Date() - months(6)
)
plot_decoupling(decoupling_runs_6mo)

# Example 2: Plot Decoupling trend for Rides
decoupling_rides <- calculate_decoupling(
  activities_data = activities,
  export_dir = "strava_export_data",
  activity_type = "Ride",
  decouple_metric = "power_hr"
)
plot_decoupling(decoupling_rides)

# Example 3: Plot Decoupling trend for multiple Run types (no trend line)
decoupling_multi_run <- calculate_decoupling(
  activities_data = activities,
  export_dir = "strava_export_data",
  activity_type = c("Run", "VirtualRun"),
  decouple_metric = "pace_hr"
)
plot_decoupling(decoupling_multi_run, add_trend_line = FALSE)
} # }
